SR380 Rotary Device
Use this robust rotary device for circumferential marking around the outside diameter of components.
Product Details
SR380 is a robust rotary axis ideal for 360° radial laser marking. The unit features a manual three-jaw-holding chuck but can be upgraded to a manual or pneumatic 5C collet closer. When provided independent of a laser workstation, the SR380 is supplied with an axis control box including drive and power supply.
- Manual 100mm 3-Jaw Chuck
- Optional Upgrade to Manual or Pneumatic 5C Collet Closer
- Includes Custom Mounting Plate
- Radial Part Marking on OD parts
- Holding Diameters of 3-80mm (ID/OD)
- Mechanical Key for Chuck Open/Close
- Outside Jaws Holding Specifications
- OD Clamping: 2-30mm
- ID Clamping: 30-90mm
- Inside Jaws Holding Specifications
- OD Clamping 30-80mm
