ZD80 Rotary Device
Use this device for circumferential marking around the outside diameter of components.
Product Details
The ZD80 is a robust, rugged rotary axis incorporating a stepper motor with a play-less timing belt and is capable of a 100% duty cycle operation. ZD80 has a 34mm diameter through-hole allowing longer components to be marked. When provided independent of a laser workstation, the ZD80 is supplied with an axis control box including drive and power supply.
- Available with a 100mm Manual 3-Jaw Chuck
- Includes Custom Mounting Plate
- Reduction Ratio: 1:8.1
- Drive Revolution: 0-120 1/min
- Operating Moment: 12 Nm
- Nominal Holding Torque: 20 Nm
- Minimum Increment: 2.6 Minutes
- Weight: 24.7 lbs
- Standard Chuck Diameter:125mm
- Through Hole Diameter: 34mm
TYKMA Electrox ZD80 Rotary Device
