What Are the Differences Between Laser Marking, Laser Engraving and Laser Etching?

At TYKMA Electrox, our team specializes in precision laser marking, engraving, and etching systems, offering unparalleled expertise in the field.

Whether your application requires intricate markings, detailed engravings, or precise etchings on diverse materials, our advanced laser marking systems deliver the exceptional performance and repeatability you need to get the job done.

Our cutting-edge technology and skilled professionals are here to ensure high-quality results no matter what industry you’re working within. Explore our comprehensive guide below to understand the key differences between laser marking, engraving, and etching, and discover how our solutions can meet your specific needs.

Comprehensive Guide to Laser Marking, Laser Engraving, and Laser Etching

Thanks to industrial and government regulations regarding clearly legible product and part identification, the processes of laser marking, laser etching, and laser engraving are increasing in popularity.

All three of these laser services provide permanent laser marking solutions, fulfilling regulations and adding distinction to your products and parts. But what sets them apart?

While the three techniques may seem similar, there are actually quite a few differences between them.

The differences between laser marking, laser engraving, and laser etching largely have to do with what each process does to the marking surface, including how deep the laser goes and how it changes the overall appearance.

Laser marking discolors the surface of the material, while laser etching and engraving actually removes a portion of the surface area as it marks. The major difference between laser etching and laser engraving is the depth to which the laser penetrates the surface.

Throughout this post, we will give you an overview of each of the processes and their applications to help you better determine which is right for your application needs.

Comprehensive Guide to Laser Marking, Laser Engraving, and Laser Etching

• Laser Marking Process
• Laser Engraving Process
• Laser Etching Process
• Laser Overview
• What a Laser Does
• Industries We’ve Served
• Essential Compliance with Laws and Regulations
• Importance of Part Traceability
• Our Industry-Leading MOPA Fiber Laser Technology
• Reach Out to Our Team

The Main Differences Between Laser Marking, Etching and Engraving

Although these terms are often used interchangeably, there are differences between laser marking, laser etching, and laser engraving. Each type of process has its own applications and attributes that make it ideal for different jobs.

Laser Marking, Etching and Engraving Demonstration

TYKMA Electrox fiber laser systems are ideal for all types of laser marking, etching and engraving in a variety of materials and substrates.

The Laser Marking Process

Laser marking is what happens when the beam interacts with the surface of a material, slightly altering its properties or appearance. Some of the features of the laser marking process include the following:

• It is achieved by moving a low-powered beam slowly across the material using a method called discoloration, which creates high-contrast marks without disrupting the material
• Laser heats the material, causing oxidation under the surface and turning the material black
• It applies low temperatures to metal to anneal the surface
• All of this is done while leaving the surface intact

Laser marking differs from laser engraving and laser etching in a number of ways, including the following:

• It is less common and not all places offer these services
• It is also referred to as laser coloration or laser dark marking, as well as charring for plastic materials and annealing for metals
• There are four common types of laser marking: annealing, carbon migration, foaming and coloration
• It’s popular in the medical device industry for stainless steel and titanium parts, but can be performed on other materials as well
• Laser marking is ideal for bar codes, UID codes, QR codes, logos and other identification needs

Back to top of page

The Laser Engraving Process

Laser engraving is a process where the laser beam physically removes the surface of the material to expose a cavity that reveals an image at eye level.

• High heat is created during the laser engraving process, which essentially causes the material to vaporize
• It’s a quick process, as the material is vaporized with each pulse
• This creates a cavity in the surface that is noticeable to the eye and touch
• To form deeper marks with the laser engraving system, repeat with several passes

Although laser engraving is a subsection of laser marking, it still differs in many ways:

• There are three types of laser engraving: etching, deep laser engraving, and laser ablation (the difference between the three is what the surface is and how much you remove)
• This is the most common option for people who want something personalized or customized
• Laser engraving is not ideal for marking safety critical parts
• The maximum engraving depth is 0.020″ in metals but can go as deep as 0.125″ in materials such as graphite
• This is the fastest way to mark with a laser
• It’s great for parts expected to experience high wear
• It’s typically used to laser engrave serial numbers and logos, among other things
• You can engrave on almost any kind of metal, plastic, wood, leather, and glass surface

Another important comparison to make is how laser engraving compares to traditional engraving practices include:

• It can be done on a variety of materials
• It is more legible than traditional engraving for small objects, such as jewelry and watches
• It provides you with more font and style options
• There is a smaller chance of product damage or deformation over time
• Laser engraving machines are faster than traditional methods

Back to top of page

The Laser Etching Process

Laser etching, which is a subset of laser engraving, occurs when the heat from the beam causes the surface of the material to melt.

• The laser beam uses high heat to melt the surface of the material
• The melted material expands and causes a raised mark
• Unlike laser engraving, the depth in laser etching is typically no more than 0.001”

The differences between laser etching, marking and engraving include:

• Since a laser etcher changes the surface finish of metals, it alters its reflectivity and enhances contrast
• It removes 0.001″ or less of the material
• It can be done on bare, anodized, or plated metal surfaces, as well as polymers and ceramics

Back to top of page

A Brief Overview of Lasers

Let’s take a step back now and explain what exactly a laser is and how it works.

“Laser” is actually an acronym that stands for Light Amplification by the Stimulated Emission of Radiation. Throughout the years, the laser has become one of the most powerful manufacturing tools a company can use.

In order to create a laser, you raise the energy level of the atoms to an excited state, which enables them to release light as they fall back to their original energy, or ground state.

But What Is a Laser Doing?

If we look back at the second word in the acronym, amplification, we will gain a better understanding of what a laser does. Once this beam of light is created, it is amplified to produce a focal point.

As the atoms begin to move, they create a weak light, and as more energy is added, the light waves become very concentrated. Unlike with other types of light (such as a flashlight), the light rays emitted from lasers all have the same wavelength and are coherent, which is what makes it such a powerful concentration of energy.

Back to top of page

Who Uses Lasers and Laser Engraving Systems?

The laser is one of the most versatile modern inventions. Laser etching, marking, and engraving are used in almost every industry, including:

• Automotive
• General industrial
• Electronics
• Medical
• Military & defense
• Aerospace
• Products & goods
• Oil & gas and much more

Each industry has its own uses for lasers. In the manufacturing industry, for example, laser marking systems are used in a variety of everyday tasks, such as welding, cutting, cleaning, measuring, drilling, and sensing, as well as marking, etching, and engraving.

While there are other ways to mark materials, such as dot peen marking, they don’t give you the quality or environmentally friendly markings that you get with laser marking, laser etching, or laser engraving technologies.

Back to top of page

Contact Us

Why Does Your Business Need Laser Marking, Laser Etching and Laser Engraving?

Whether you work in the automotive, aerospace, or medical device industry and you are working from a desk, you understand the importance of part identification. For each division of manufacturing, there are laws and regulations put in place regarding identification to reduce error and ensure part safety.

What Are the Laws?

In the medical device industry, the Food and Drug Administration released a final rule in 2013 requiring all manufacturers to include a unique device identifier (UDI) on device labels and packages, except where the rule provides for an exception or alternative; but as of September 2018, the FDA ruled that there must be visible dates on the labels of all devices, regardless if they are excepted from the 2013 rule. A UDI is a unique numeric or alphanumeric code that consists of two parts: a device identifier (DI) and a production identifier (PI). As of October 2022, the ruling is still in effect.

The DI is a fixed portion that identifies the labeler and the version or model of the device, while the PI is used to identify several things, including the serial number, expiration date and the distinct identification code required for a human cell, tissue, or cellular and tissue-based product (HCT/P) regulated as a device.

The notion of part traceability is similar to that utilized by automotive and aerospace part manufacturers.

In the aerospace industry, engines, propellers and other replacement and modification parts are required to include certain registration and identification marking. The Federal Aviation Administration (FAA) determines which information is appropriate to include, such as the builder’s name, model designation and certification – if any – among other things. These markings are required to be on a fireproof dataplate or a similarly approved fireproof method.

Back to top of page

Why Is Part Traceability Important?

Regulations for the medical device industry, the aerospace industry, and the automotive industry are designed to help increase safety for all types of parts.

For example, automotive companies utilize part traceability to increase safety and reliability in their vehicles. If a component fails, the manufacturer can quickly and easily determine when and where the part was produced, allowing for critical recalls and warranty decisions to be made sooner.

Back to top of page

Industry-Leading Laser Marking, Engraving and Etching Machines from TYKMA Electrox

At TYKMA Electrox, we provide our customers with the best technology, which is why we offer the most advanced laser marking, laser engraving and laser etching machines in the world.

Our Master Oscillator Power Amplifier (MOPA) fiber laser technology has the capability to mark, engrave or etch on a variety of surfaces and materials, unlike other fiber laser marking systems that often have trouble processing some difficult or sensitive materials. Our machines allow you to easily engrave, mark or etch on materials ranging from gold and nickel plating to plastics and PCB.

Other benefits of our MOPA laser-powered marking, engraving and etching machines include:

• Ten times more efficient than traditional YAG laser systems
• Available from 10 to 100 watts of power
• Maintenance-free design
• No lamps, water cooling or alignments
• Require no calibrations
• Longest reliability, with up to 100,000-hour lifespans and industry-leading warranties
• Compact machine with simple design

Throughout the years, we’ve also expanded the capabilities of our machines to ensure that we can meet the diverse needs of the manufacturing industry.

From our color and 3D marking capabilities to our systems designed to work with multiple devices, our constant innovation is what has set us apart from other laser engraving machine manufacturers.

Back to top of page

Contact Us Today to Learn More

With our laser etching, laser engraving and laser marking systems, you can achieve the clear, high-quality marks your company needs.

To learn more about our laser machines, and what they will accomplish for you, be sure to contact us and we’ll be happy to answer any questions you may have.
