Minilase™ XL Laser Marking System
Minilase™ XL is a mid-size benchtop laser marking system with a unique three-side automatic operator door for high volume applications.
Product Details
Minilase™ XL provides an open interior for larger components in a benchtop system. In addition, Minilase™ XL is equipped with ergonomic features such as the three-side pneumatic vertical door with patented safety system, power focal height adjustment, and auto-mode for high-volume applications. A service override key and safety warning light allow for open door Class 4 marking capability for extra-large components. Minilase™ XL is air cooled, maintenance-free and includes a comprehensive three-year warranty.
Laser Marking System Features
- Class 1 Safe Benchtop Laser Enclosure
- Front Operator Membrane Control Panel
- Three-Side Vertical Pneumatic Door with Patented Safety System and Auto Start Mode
- 20W, 50W, 60W, 70W, or 100W MOPA Fiber Laser
- Power Focal Height Adjustment with Built-In Focus Finder Tool
- Optional Upgrade to Programmable Focal Height Adjustment
- Class 4 Mode with Interlock Override Key, Warning Light, and Laser Safety Glasses
| Laser Specifications | |||||
| Laser Type | MOPA Fiber | ||||
| Wavelength | 1062nm +/-3 nm | ||||
| Wattage Ratings | 20W | 50W | 60W | 70W | 100W |
| Frequency Range (kHz) | 1-4,000 | 1-500 | 1-4,000 | 1-500 | 1-2,000 |
| Pulse Duration |
16 Available |
40 & 260ns | 17 Available 2-500ns, CW |
40 & 260ns | 49 Available 6-2,020ns, CW |
| Operative Ambient Air Temp | 7°-41°C / 45°-105°F | ||||
| Cooling Type | Forced Air | ||||
| Red Alignment Laser (RAL) | Class II Red Diode (635nm) | ||||
| Red Focusing Laser (RAL) | Class II Red Diode (635nm) | ||||
| Power Requirement | Power Sensing 110-240 VAC 50/60 Hz | ||||
| Standard F-Theta Focal Lens | |
| Lens Size / Marking Field | 163L M85 – 100mm x 100mm 3.93″x 3.93″ |
| Max Part Height | 251.6mm / 9.9″ |
| Optional F-Theta Focal Lens Upgrades | |
| Lens Size / Marking Field | 254L M85 – 165mm x 165mm 6.5″ x 6.5″ |
| Max Part Height | 151.2mm / 5.9″ |
| Lens Size / Marking Field | 330L M85 – 200mm x 200mm 7.87″ x 7.87″ |
| Max Part Height | 76.41mm / 3″ |
| System Specifications | |
| Dimensions (LxWxH) | 1,079mm x 610mm x 851mm 42.5″ x 24″ x 33.5″ |
| Height with Door Open | 1,211mm / 47.7″ |
| Weight (approx.) | 91kg / 200lbs |
| Max Part Size (LxW) | 317mm x 508mm 12.5″ x 20″ |
| Laser Focus Control | Power (Prog. Upgrade Available) |
| Door Type | Automatic with Patented Safety |
| Air Required for Door Operation | 60-80 PSI |
| Available Software Packages | Minilase Pro SE Minilase Pro 3 64-Bit |
| PC | Windows 10 PC Required for Operation |
| External Connectors | VGA / USB (2) / Diagnostic / Ethernet / Automation Mode Connector |
| Fume Extraction Connection Port | Included |
| Included Accessories | Laser Enable Keys (2) / Power Cable / USB Drive with Software Backup / Class 4 Service Override Key |
| Documentation (Digital on USB) | System Manual / Software Manual / Laser Parameters Guide / Software Video Tutorials |
MOPA Fiber Laser
Our MOPA fiber laser technology marks all metals, most plastics, carbide, anodized aluminum, painted or coated materials and more. MOPA fiber lasers enhance the marking capabilities over basic q-switched fiber laser systems. Selectable pulse durations allow for the processing of a wider variety of materials and substrates.
Minilase™ Pro Design Software
With our user-friendly software, operators and engineers can quickly create marking files with text, barcodes, 2D codes, and a variety of graphic formats such as DXF, AI, PLT, BMP, and JPEG. CAD tools allow users to draw their own graphics and manipulate complex vector files. Automated date coding and serialization capabilities are also included. A preconfigured materials library takes the guess work out of setting up laser marking parameters. Control a rotary device for 360° marking.
Icon Interface Software
Icon Interface, our off-the-shelf operator interface enables the following: advanced network data retrieval, TCP/IP communication protocol, SQL server connectivity, PLC interfacing, detailed photographic part fixture instructions and displays, operator restrictions and password protection, data entry via barcode scan, and more. Need additional capability? Let us create it for you!
TYKMA Electrox Product Brochure
DownloadMajor Features
Midsized Benchtop Enclosure
Minilase™ XL is a midsize Class 1 benchtop laser enclosure, providing safe operator use without the need for protective eyewear.
Focus Finder Tool
Easily focus Minilase™ XL by aligning the two red laser dots on the surface of your material using the standard power focal height adjustment. Upgrade to programmable focal height adjustment for automatic focus.
Ergonomic High-Volume Design
Minilase™ XL is ideal for high-volume applications. The three-side pneumatic door opens and closes automatically with each marking cycle. In addition, the system can be put into Class 4 mode to mark larger parts with the door open.
